TC40H174P – DIP

Name: TC40H174P - DIP
SKU: 2901
Availability: InStock

ریال130.680

Hex D-type flip-flop-CMOS

28 در انبار

شناسه محصول: 2901 دسته: CMOS Logic, آی سی ها

Product Category: Flip-Flops
- Manufacturer: Texas Instruments
- RoHS: RoHS Compliant Details
- Number of Circuits: 7
- Logic Family: CD4000
- Logic Type: D-Type Flip-Flop
- Polarity: Non-Inverting
- Input Type: CMOS
- Output Type: CMOS
- Propagation Delay Time: 300 ns
- High Level Output Current: – 1.5 mA
- Low Level Output Current: 1.5 mA
- Supply Voltage – Max: 18 V
- Maximum Operating Temperature: + 125 C
- Mounting Style: Through Hole
- Package/Case: PDIP-16
- Packaging: Tube
- Brand: Texas Instruments
- Function: Hex
- Height: 4.57 mm
- Length: 19.3 mm
- Minimum Operating Temperature: – 55 C
- Number of Channels: 6
- Number of Input Lines: 6
- Number of Output Lines: 6
- Operating Supply Voltage: 10 V
- Operating Temperature Range: – 55 C to + 125 C
- Quiescent Current: 20 uA
- Reset Type: Master Reset
- Series: CD40174B,HCF0174B,HEF40174B,TC40174B
- Factory Pack Quantity: 25
- Supply Voltage – Min: 3 V
- Width: 6.35 mm
- Unit Weight: 1 g
- آی سی 40174 شامل 7 عدد فلیپ فلاپ نوع D می باشد.
