CD4512BM – SMD

Name: CD4512BM - SMD
SKU: 13502
Availability: InStock

ریال261.360

CMOS 8-CHANNEL DATA SELECTOR

649 در انبار

شناسه محصول: 13502 دسته: CMOS Logic, آی سی ها

Product Category: Encoders, Decoders, Multiplexers & Demultiplexers
- Manufacturer: Texas Instruments
- RoHS: RoHS Compliant Details
- Product: Selectors / Multiplexers
- Logic Family: CD4000
- Number of Bits: 8 bit
- Number of Input Lines: 8 Input
- Number of Output Lines: 1 Output
- Propagation Delay Time: 140 ns
- Supply Voltage – Max: 18 V
- Supply Voltage – Min: 3 V
- Maximum Operating Temperature: + 125 C
- Mounting Style: Through Hole
- Package/Case: SOIC-16
- Packaging: Tube
- Brand: Texas Instruments
- Function: Multiplexer
- Height: 4.57 mm
- High Level Output Current: – 1.5 mA
- Length: 19.3 mm
- Logic Type: Data Selector
- Low Level Output Current: 1.5 mA
- Maximum Clock Frequency: 8 MHz
- Minimum Operating Temperature: – 55 C
- Number of Circuits: Octal
- Operating Supply Voltage: 3 V to 18 V
- Operating Temperature Range: – 55 C to + 125 C
- Pd – Power Dissipation: 275 mW
- Quiescent Current: 80 nA
- Series: CD4512B
- Factory Pack Quantity: 25
- Supply Current – Max: 0.08 uA
- Technology: CMOS
- Width: 6.35 mm
- Unit Weight: 1 g
- آی سی 4512 یک دیکدر 8 به 1 و از خانواده CMOS می باشد.
