CD4053BE – DIP

Name: CD4053BE - DIP
SKU: 2969
Availability: InStock

ریال267.894

MB84053 2-Ch Analog Mux/Dmux-CMOS

167 در انبار

شناسه محصول: 2969 دسته: CMOS Logic, آی سی ها

Product Category: Multiplexer Switch ICs
- Manufacturer: Texas Instruments
- RoHS: RoHS Compliant Details
- Product: Multiplexers/Demultiplexers
- Number of Channels: 3 Channel
- Configuration: 3 x 2:1
- On Resistance – Max: 240 Ohms
- On Time – Max: 720 ns
- Off Time – Max: 450 ns
- Operating Supply Voltage: 5 V to 18 V
- Maximum Operating Temperature: + 125 C
- Mounting Style: Through Hole
- Package/Case: PDIP-16
- Bandwidth: 30 Mhz
- Brand: Texas Instruments
- Height: 4.57 mm
- Length: 19.3 mm
- Maximum Dual Supply Voltage: +/- 9 V
- Minimum Operating Temperature: – 55 C
- Packaging: Tube
- Propagation Delay Time: 60 ns
- Series: CD4053B , HEF4053B , HCF4053
- Factory Pack Quantity: 25
- Supply Current – Max: 100 uA
- Supply Type: Single Supply, Dual Supply
- Supply Voltage – Max: 18 V
- Supply Voltage – Min: 5 V
- Width: 6.35 mm
- Unit Weight: 1 g
- آی سی CD4053BE شامل 3 مالتی پلکسر 2 به یک می باشد.
