74LS137 – DIP

Name: 74LS137 - DIP
SKU: 3095
Availability: OutOfStock

ریال96.082

TTL 74137- 3-TO-8 LINE DECODER

در انبار موجود نمی باشد

شناسه محصول: 3095 دسته: TTL Logic, آی سی ها

Product Category: Encoders, Decoders, Multiplexers & Demultiplexers
- Manufacturer: Texas Instruments
- Product: Decoders / Demultiplexers
- Logic Family: 74LS
- Number of Input Lines: 3 Input
- Number of Output Lines: 8 Output
- Supply Voltage – Max: 5.25 V
- Supply Voltage – Min: 4.75 V
- Maximum Operating Temperature: + 70 C
- Mounting Style: Through Hole
- Package/Case: PDIP-16
- Brand: Texas Instruments
- Function: Latch/Decoder/Demultiplexer
- Height: 4.57 mm
- High Level Output Current: – 0.4 mA
- Length: 19.3 mm
- Logic Type: Decoders/Demultiplexers
- Low Level Output Current: 8 mA
- Minimum Operating Temperature: 0 C
- Number of Circuits: 1 Circuit
- Operating Supply Voltage: 5 V
- Operating Temperature Range: 0 C to + 70 C
- Series: SN74LS137
- Supply Current – Max: 11 mA
- Technology: Bipolar
- Width: 6.35 mm
- Unit Weight: 1,628 g
- آی سی 74137یک دیکودر 3 به 8 می باشد.
