74HC138 – SMD

• Manufacturer: Texas Instruments
• PRoduct Category: Encoders, Decoders, Multiplexers & Demultiplexers
• RoHS: RoHS Compliant Details
• Product: Decoders / Demultiplexers
• Logic Family: HC
• Number of Input Lines: 3 Input
• Number of Output Lines: 8 Output
• Propagation Delay Time: 30 ns
• Supply Voltage – Max: 6 V
• Supply Voltage – Min: 2 V
• Maximum Operating Temperature: + 125 C
• Mounting Style: Through Hole
• Package/Case: SO-16
• Packaging: Tube
• Brand: Texas Instruments
• Function: Decoder/Demultiplexer
• Height: 4.57 mm
• High Level Output Current: – 5.2 mA
• Length: 19.3 mm
• Logic Type: Decoders/Demultiplexers
• Low Level Output Current: 5.2 mA
• Maximum Clock Frequency: 28 MHz
• Minimum Operating Temperature: – 55 C
• Number of Circuits: Dual
• Operating Supply Voltage: 2 V to 6 V
• Operating Temperature Range: – 55 C to + 125 C
• Series: CD74HC138
• Factory Pack Quantity: 25
• Supply Current – Max: 0.008 mA
• Technology: CMOS
• Width: 6.35 mm
• Unit Weight: 1 g

 آی سی 74138شامل یک دیکودر/دی مالتی پلکسر 1 به 8 می باشد.
